Planoconvex lens

A flat convex lens has a convex surface on one side and a flat surface on the other, and has a positive focal length. It is usually used for applications such as reducing beam size, reducing focal length, or enlarging images. To reduce spherical aberration, when a planar convex lens is used for collimating beam focusing, the beam should be incident on the surface of the lens; When used for point light source collimation, the beam is incident on a plane. Flat convex lenses are commonly used in imaging or beam collimation applications, and coated lenses are also widely used in visible and near-infrared applications.

Add to shopping cart

DETAILS


Index
material	BK7 and UV fused silica
Focal length tolerance	±1% @589nm
design wavelength	589nm
decentration	≤3′
Outer diameter tolerance	+0/-0.1mm
Effective aperture	＞90% Central area
Center thickness tolerance	±0.1mm
Edge thickness	Standard value
finish	20/10（UVFS）/ 40/20（BK7）
Face shape (within the effective aperture)	≤ 1.5λ Optical power，λ/2 Irregularity（UVFS）
	≤ 1.5λ Optical power，λ/4 Irregularity（BK7）
chamfer	0-0.8mm ×45°±15°
Other materials, outer diameter, and focal length products can be customized by Xinye Technology according to needs

Specifications
Part No	Dia	Tc	Te	R1	R2	EFL	material
Part No	(mm)	(mm)	(mm)	(mm)	(mm)	(mm)	material
LMS-254-R857-R2500-BK7	25.4	4.12	3.5	85.7	-250	250	BK7
LMS-254-R1025-R3000-BK7	25.4	4.02	3.5	102.58	-300	300	BK7
LMS-254-R1266-R3220-BK7	25.4	3.89	3.5	126.66	-322	400	BK7
LMS-254-R1554-R3876-BK7	25.4	3.81	3.5	155.466	-387.6	500	BK7
